Frame
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Size Split: 27.5: S // 29: M, L, XL
Suspension
Shock hardware Front: 30x8mm, Rear: DU-Bushing 12.7mm
Suspension fork RockShox Psylo Silver RC Air, Tapered, 15x110mm, 150mm
Shock RockShox Deluxe Select R, 230x60mm (27.5: 210x55mm), Rebound Adjust
E-bike system
Drive unit Bosch Drive Unit Performance Line CX max. 120Nm (BDU38)
Remote Bosch Mini Remote
Battery Bosch PowerTube 800
Display Bosch Kiox 400C
Charger Bosch 2A
Drivetrain & brakes
Crankset ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Brake system Magura Louise, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Rear derailleur Shimano XT RD-M8200-SGS, ShadowPlus, 12-Speed
Shifters Shimano Deore SL-M6210, Single Click
Cassette Shimano Deore CS-M6100, 10-51T
Chain KMC e12
Chain guide Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
Headset Acros AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Handlebar CUBE Rise Trail Bar 35 VariGrip System
Grips ACID Endure VariGrip System
Stem CUBE Performance Stem E-MTB 35, FPI-Link
Wheels
Wheelset ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Tyres Schwalbe Nobby Nic, Performance, 2.6
Finishing kit
Saddle ACID Venec EMTB Trail 140
Seat clamp CUBE Semi-Integrated
Seat post CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Pedals ACID PP MTB
Product information
Structural Weight 150 kg
Maximum rider weight 125 kg
Colour oldgrey´n´black
Weight 24,6 kg
